Carsfad Power Station

  • Details
  • Collections
  • Images

Filter

No Available Filters

Save Search

Log in to save your search
Carsfad Hydro Electric Power Station. Turbine House. View from north west
DP 424828
 compare
Carsfad Dam. Concrete spillway at NX 6050 8557
DP 425093
 compare
Interior. Carsfad Hydro Electric Power Station. Fish House. Original equipment
DP 425096
 compare
Carsfad Hydro Electric Power Station, Fish House. The Fish House regulates and monitors the passage of fish through the fish ladder upstream from Water of Ken into Carsfad Loch/Reservoir.
DP 425099
 compare
Interior. Carsfad Hydro Electric Power Station. Intake House. Takes water from the aqueduct. Water flow to two penstocks in turn feeding water to the two Turbines are regulated from here
DP 425103
 compare
Carsfad Hydro Electric Power Station. Intake house. View from south east looking towards screens area
DP 425109
 compare
Carsfad Hydro Electric Power Station. Turbine House. View from south south east of operating room
DP 425113
 compare
Interior. Carsfad Hydro Electric Power Station. Turbine House. View of one of the 6000Kw generator sets, its turbine sits below the set at basement level. Electrical current is generated under the light blue casing.
DP 425120
 compare
Carsfad Dam. View of needle valve house on dam
DP 424810
 compare
Carsfad Dam. East side of walkway, outlet needle valve house on extreme left
DP 425080
 compare
Carsfad Dam. View from east of dam, spillway and outlet needle valve house (right)
DP 425082
 compare
Carsfad Dam. View looking onto outlet needle valve house
DP 425088
 compare
Interior. Carsfad Dam. Valve House. Sluice gate for controlling water flow to needle valve. The gate is made of steel rollers that can be lowered up and down within the valve house
DP 425089
 compare
Interior. Carsfad Hydro Electric Power Station. Turbine House. Elevated view showing both electricity generating units
DP 425114
 compare
Interior. Carsfad Hydro Electric Power Station. Turbine House, Operation Room. Voltage regulation board
DP 425117
 compare
Interior. Carsfad Hydro Electric Power Station. Turbine House, view along south side from west
DP 425121
 compare
Interior. Carsfad Hydro Electric Power Station. Turbine/Power House, ground level. Concrete platform on which generator set sits
DP 425128
 compare
Interior. Carsfad Hydro Electric Power Station. Turbine/Power House. Shaft running from turbine below to rotor above in generator set
DP 425130
 compare
General view from SW. Copy of 35 mm colour transparency.
SC 875571
 compare
Oblique aerial view centred on the loch with the dam and power station to the left, taken from the E.
DP 030193
 compare
Oblique aerial view centred on the dam and power station, taken from the NW.
DP 030194
 compare
Oblique aerial view centred on the dam and power station, taken from the WNW.
DP 030195
 compare
Carsfad Hydro Electric Power Station, Turbine House. Interior. View of original telephone call box.
DP 424820
 compare
Interior. Carsfad Hydro Electric Power Station, Turbine House. Operating Room, first floor adjacent to Loading Bay (roller shutter visible on right). DC Board (left) and Metering Board (right).
DP 424821
