Stirling Railway Station, Middle Signal Box

  • Details
  • Collections
  • Images

Filter

No Available Filters

Save Search

Log in to save your search
Interior. Locking Room, track side. Detail of pulley wheels guiding signal chain and wire, attached to lever and to signal bar above, which run under the walkway on south west side of signal box.
DP 143293
 compare
Interior. Locking Room. Vertical Locking Tray and levers, track side. Detail. The [sword] tappets are visible at the top of the locking tray. The Locking Tray contains locking bars which connect to dogs to other dogs allowing locking or movement of the tappets (in turn connected to the levers operated from the first floor of the signal box). This is a Glasgow 'new style' design of vertical locking tray.
DP 143299
 compare
Interior. Locking Room. View along locking frame which sits below the bench (frame which guides the signal levers at first floor level), from south. Here we see a weighted lever painted black and yellow. These give extra purchase to levers which operate far flung signals. In this case, a signal 456 yards away from the signal box. The locking tray, levers and tails are visible.
DP 143307
 compare
Interior. Locking Room. Detail of frame where signal levers removed.
DP 143311
 compare
nterior. Locking Room. Locking frame timber with later inserted pillar.
DP 143313
 compare
Interior. Locking Room. Locking frame, detail of Stevens end frame. The frame has the bench at the top which guides the levers as they engage and disengage with the locking tray via the tappets attached to the levers. the tappets then engage with the locking tray mechanism. The lever tails in turn move the pulley chains and wires which operate the signals.
DP 143316
 compare
Interior. Locking Room. Locking frame, detail of Stevens end frame.
DP 143317
 compare
Interior. Locking Room. Locking frame, detail of timber framing supporting Stevens frame.
DP 143318
 compare
Interior. Locking Room, from north west, locking tray at top of picture, levers and their tails. the chains attached to the lever tails engagewith wires which operate the signals soem distance from the signal box.
DP 143320
 compare
Interior. Locking Room. Locking frame timber support resting on brick built plinth.
DP 143323
 compare
View of east side of box showing signal operating wires.
DP 143328
 compare
View of east side of box showing signal operating wires.
DP 143331
 compare
View of box from south.
DP 143335
 compare
Interior. Signal Box. Lever Frame (96 levers) by Stevens, Glasgow Pattern. The floor below this is called the Locking Room. this contains the locking frame apparatus which operates the signals via levers, pulleys, chains and wires.
DP 143339
 compare
Interior. Signal Box. Detail of lever as it meets bench, by Stevens, Glasgow Pattern.
DP 143344
 compare
Interior. Signal Box. Detail of lever bench name plate, south end, by Stevens, Glasgow Pattern
DP 143351
 compare
Interior. Signal Box. Alloa Line modern signalling system.
DP 143363
 compare
Interior. Signal Box. Alloa Line modern signalling system.
DP 143365
 compare
Interior. Signal Box. Signalman operating levers.
DP 143371
 compare
Interior. Signal Box. Rear of lever bench
DP 143378
 compare
Interior. Locking Room. Detail. Locking frame, track side. Stirrup connections to vertical or predestal 'L' cranks.
DP 143295
 compare
Interior. Locking Room. Opening for signal connections from vertical locking frame to signals.
DP 143305
 compare
Interior. Locking Room. Opening for connections pulleys and tension wires and signal chains.
DP 143308
 compare
View of east side of box showing signal operating wires.
DP 143329
